Airmar SS175H 0 Degrees CHIRP 1kW - Mix and Match

he low profile Airmar SS175H 1KW Chirp ready transducer is the perfect addition to a smaller boat. The High frequency band is excellent for pinpointing fish holding to tight to structures and has amazing target separation on bait fish and gamefish.

The SS175H delivers up to 80 kHz of total bandwidth in just one installation, and provides superior shallow water performance and bottom detail.

To compensate for your boats deadrise, the high-performance ceramic elements are tilted inside the housing. As a result this aims the beams straight toward the bottom, resulting in stronger echo returns and more accurate depth readings.

Refer to the images for detail on the Beamwidth, Beam Diameter and Depth.

Suitable for Metal Hull Types.

Tilt Angle Variations:

0° tilted for 0° to 7° hull deadrise
12° tilted Available by special order (Not stock item)
20° tilted for 16° to 24° hull deadrise

Mix and Match Brand Fitment:

Furuno
Garmin
Humminbird
Simrad

Features

Depth and fast-response water-temperature sensing

1 kW of power with a maximum depth of 304 m (1000')
High frequency: 130 to 210 kHz
10° to 6° beamwidth
80 kHz of total bandwidth from one transducer
High frequency delivers superior shallow-water performance, bottom detail, and fish-target separation
Low-profile, thru-hull housing provides good display resolution at speed when installed properly
Recommended for stepped, planing, or displacement hull
Stainless steel housing for use in all hull materials
Also available in a bronze housing (B175H) for use in a fiberglass or wood hull
Patented Xducer ID technology
