Iris PHOTON 4K UHD Ultra Low Static IP Camera - Black & White
Introducing the ground-breaking new Photon Ultra Hi-Def / Ultra Low Light Night Vision Camera from Iris, available in 12mm and 2.8mm lens options for long range and wide angle applications.
Photon uses state of the art video processing technology combined with AI analitics to enhance its ultra high definition 4K (3840 x 2160) output, producing full colour, realtime (25Hz) video in virtually pitch black conditions. Even in moonless skies, with just the faintest starlight, Photon’s cutting edge processor analyzes each of its 8.3 million pixels, dynamically boosting and enhancing the output stream.
In addition to the camera’s dynamic video processing, an integrated soft white LED illuminator is included to enhance visibility at short range.
Designed to overcome the shortcomings of expensive thermal imaging cameras, Photon is not bound by strict export controls, doesn’t struggle in low thermal contrast scenarios, and isn’t affected by lead time issues accentuated by geopolitical conflicts.
The camera’s staggering ultra high definition output instantly adds value to leading chart-plotters offering 4K support, such as Garmins’ superb 9000 series range*. Even if your display can’t offer UHD, Photon can be configured to output video as required.
As the camera is powered via IEEE802.3af Power over Ethernet (PoE), installation couldn’t be simpler, requiring a single CAT5 cable, and just 4 drill holes (plus cable entry).
If you need to run at night and don’t want the hassle or price tag of a thermal camera, Photon takes the heat out of night vision and leads the way!
## Features##
Features
- 4K Ultra Hi-Definition Resolution(3840 x 2160) – 8.3MP
- Ultra Low Light Operation: 0.0003 Lux
- Full Colour Video in Starlight Conditions
- Remote Viewable
- Soft White LED Illumination for Enhanced Short Range Illumination / 100ft
- 12mm (long range) & 2.8mm (wide angle) Lens Options
- Power over Ethernet (PoE) IEEE802.3af
- Compatible with Leading Chart Plotters
- Available in All White / Matte Black & White & Black Mix
- Multiple Streams
- EN60945 EMC Compliant
- NDAA Compliant
- ONVIF Compliant
- Environmental Rating: IP67
## Features##
## Specifications##
| Specifications Chart | |
| Sensor | 1/1.2” CMOS Sensor |
| Resolution | 8MP (3840*2160)@ 30/25fps; 5.3MP (3072*1728)@ 30/25fps; 3.6MP (2560*1440) @30/25fps; 2MP (1920*1080) @30/25fps; 720P (1280*720), Max |
| Protocols | IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, SSL/TLS, SSH, ONVIF (Profile S, Profile G, Profile T, Profile M) |
| Compression | U265, H.265, H.264, MJPEG |
| Minimum Illumination | Colour: 0.0003 lux (F1.0, AGC ON) |
| Shutter | Auto/Manual 1 to 1/100000 s |
| Adjustment Angle | Pan: 0Ëš ~ 360Ëš / Tilt: TBC - Manual Adjustment |
| S/N | >56 dB |
| WDR | 130dB |
| Lens | 12mm (Standard) / 2.8mm (Option) |
| Iris Type | Fixed |
| Iris | F1.0 |
| Field of View | 12mm Model: 54Ëš(H) x 30.7Ëš(V) x 63Ëš(D) / 2.8mm Model: 105Ëš(H) x 56.1Ëš(V) x 121Ëš(D) |
| Web Browser Compatibility | With Plugin: IE 10+, Chrome 45+, Firefox 52+, Edge 79+ / Without Plugin: Chrome 57+, Firefox 58+, Edge 16+ |
| Power | DC12V ±25%, PoE IEEE802.3af / Max 6.0W |
| Security | NDAA Compliant |
| Operating Temperature | -20ËšC ~ +60ËšC |
| Environmental | EN60529 IP67 |
| EMC / Safety | EN60945 Sections 9 & 10, EN55032, EN6100033, EN50130 / EN623681 |
| Weight & Dimensions | 1.2KG / 139mmø x 150(h) |
## Specifications##
