Naval Brass Sleeve Cutless Bearing - Metric

(No reviews yet) Write a Review
Availability:
<span style="color: red; font-weight: bold; font-size: 1.1em;">Special Order item, could be 2-3 Months, check availability before ordering</span>

Description

Naval Brass Sleeve Cutless Bearing - Metric

Manufactured with a non-metallic outer sleeve designed for applications where corrosion or electrolysis may be of some concern. The bearing features a dense outer case structure of engineered reinforced thermo plastic for rigidity and fit. The specially compounded nitrile rubber is securely bonded to the shell with all tolerances maintained to ensure proper lubrication integrity. Johnson employs the highest quality materials that are inherently resistant to all known chemicals, oil and grease to ensure a non-corrosive anti-electrolytic bearing. Johnson non-metallic Cutless® brand propeller shaft bearings have full type approval from the American Bureau of Shipping and are available in imperial and metric sizes for shaft diameter from 3/4″ to 6-1/2″ (19.05mm to 165.10mm).

BLA Code
Description
Supplier Code
Shaft Diameter mm
Outside Diameter mm
Length mm
Metal Thickness mm
Weight kg
190402-BLA Cutless Bearing Br 870 30 x 45 x 120mm Bs 870304100 30mm 45mm 120mm 3.07mm 0.5kg
190410-BLA Cutless Bearing Br 870 40 x 55 x 160mm Bs 870404100 40mm 55mm 160mm 3.07mm 0.8kg
190416-BLA Cutless Bearing Br 870 50 x 70 x 200mm Bs 870504100 50mm 70mm 200mm 3.26mm 1.4kg
190422-BLA Cutless Bearing Br 870 80 x 100 x 320mm Bs 870804100 80mm 100mm 320mm 3.17mm 3.5kg
