Description

JL Audio XDM Car And Marine Amplifier, 5 Channel, 1000W - XDM1000/5

5-Channel Class D Car/Marine System Amplifier, 100 W x 4 @ 2 Ω + 600 W x 1 @ 2 Ω - 14.4V

With NexD technology, XDM amplifiers achieve total amplifier efficiencies exceeding 80%. This results in reduced energy use, making them much kinder to your electrical system.

MULTIPLE CONFIGURATIONS TO FIT NEARLY ANYWHERE

EXCLUSIVE INPUT FILTER FOR AMAZING AUDIO ON LAND OR SEA

EFFICIENT DESIGN FOR HIGH OUTPUT USES LESS ENERGY

FULL SUITE OF STUDIO-GRADE SIGNAL PROCESSING ON BOARD

UNIQUE DESIGN ADJUSTS OPERATION TO AVOID THERMAL EVENTS

2-YEAR WARRANTY

FIDELITY FOR ALL
Our exclusive dual-mode input filter and differential-balanced inputs result in outstanding noise rejection and crystal-clear audio performance in boats or cars.

EQUIPPED WITH NexD
Advanced switching technology for exceptional efficiency reduces current draw and heat, permitting reliable high-power output from a compact and easy-to-install chassis.

STUDIO-GRADE SIGNAL PROCESSING
Beneath every XDM amplifier’s sealed security cover, you’ll find audiophile-grade signal processing with fully variable filters and calibrated potentiometers.

ADVANCED ROLLBACK PROTECTION
Innovative circuit design ensures the amplifier will never shut down due to thermal overload and keeps the music playing, even under the most demanding conditions.

AUTO TURN-ON CAPABILITIES
Choose from 3 options: auto signal sensing with +12-volt remote out; auto DC-offset sensing with +12-volt remote out; or conventional +12 volt turn-on lead.

BUILT TOUGH
The all-aluminium, powder-coated housing inhibits corrosion, and a sealed security cover protects controls from the elements.

CHOOSE YOUR MODEL

FULL-RANGE STEREO
These amplifiers are available in 2, 4, 6 and 8 channel variants.

SYSTEM AMPLIFIERS
There are 3 models to power a whole system with 2 or 4 full-range outputs plus a subwoofer output.

MONOBLOCK
Three models are available with 300, 600 and 1000 watts.

24-VOLT OPTIONS
These amplifiers are available in 6 and 8 channel variants.

##Features##

Features

Five-channel gear powers whole setup
High efficiency helps 12 V systems cope
Aluminium chassis handles Aussie conditions
Filters give real control over tuning
Compact footprint frees up storage space

##Features##

##Specifications##

Specifications

Amplifier type: 5-channel car and marine system amplifier (1000 W)
Amplifier class: Class D
Operating voltage: 11–14.5 VDC (12 V models)
Rated efficiency: NexD technology with total efficiency exceeding 80%
RMS power at 14.4 V and 4 Ω (5-channel 1000 W): Main channels 75 W x 4 / Subwoofer 400 W x 1
RMS power at 14.4 V and 2 Ω (5-channel 1000 W): Main channels 100 W x 4 / Subwoofer 600 W x 1
RMS power at 12.5 V and 4 Ω (5-channel 1000 W): Main channels 60 W x 4 / Subwoofer 360 W x 1
RMS power at 12.5 V and 2 Ω (5-channel 1000 W): Main channels 90 W x 4 / Subwoofer 600 W x 1
Frequency response main channels: 12 Hz – 22 kHz (+0, -1 dB)
Frequency response subwoofer channel: 10 Hz – 1 kHz (+0, -1 dB)
Signal-to-noise ratio main channels (analog inputs, A-weighted, 20 Hz – 20 kHz): > 104 dB
Signal-to-noise ratio subwoofer channel (analog inputs, A-weighted, 20 Hz – 20 kHz): > 103 dB
Signal-to-noise ratio main channels at 1 W: > 84 dB
Signal-to-noise ratio subwoofer channel at 1 W: > 83 dB
Damping factor at 4 Ω (5-channel): > 150 at 50 Hz
Damping factor at 2 Ω (5-channel): > 75 at 50 Hz
THD+N at rated power main channels: <1% at 2 Ω per channel
THD+N at rated power subwoofer channel: <1% at 2 Ω per channel
Filter modes channels 1 & 2 (5-channel 1000 W): Off or High-Pass only
Filter frequency range channels 1 & 2 (5-channel 700 W/1000 W): 50 Hz – 5 kHz
Filter slope channels 1 & 2 (5-channel 700 W/1000 W): 12 dB/octave
Filter modes channels 3 & 4 (5-channel 700 W/1000 W): Off, High-Pass or Bandpass
Filter frequency range channels 3 & 4 (5-channel 700 W/1000 W): 50 Hz – 500 Hz
Filter slope channels 3 & 4 (5-channel 700 W/1000 W): 12 dB/octave
Filter modes subwoofer channel (5-channel 700 W/1000 W): Off or Low-Pass only
Filter slope subwoofer channel (5-channel 700 W/1000 W): 12/24 dB/octave
Filter frequency range subwoofer channel (5-channel 700 W/1000 W): 50 Hz – 500 Hz
Input voltage range at RCA inputs (5-channel family): 200 mV – 4 V RMS
Pass-through preamp output: Buffered
Remote level control options: HD-RLC or MHD-RLC (water-resistant)
Remote level modes (5-channel 700 W/1000 W): All channels or Sub channels
Channel input mode switch (5-channel 700 W/1000 W): 2/4/6 channels
Physical height: 52 mm (2.05")
Physical depth: 180 mm (7.09")
Physical width (5-channel 1000 W chassis group): 374 mm (14.73")
Fuse rating (5-channel 1000 W): 80 A
Recommended fuse types: AFS, AGU or MaxiFuse
Minimum copper power/ground wire gauge (5-channel): 4 AWG
Housing material: All-aluminium, powder-coated
Protection: Sealed security cover over controls
Thermal management: Advanced rollback protection to prevent thermal shutdown
Warranty: 2 years
