Victron Orion-Tr 24/12-9A (110 W) Isolated DC-DC Converter

The Victron Orion-Tr 24/12-9 (110W) is an isolated DC-DC converter delivering up to 9A continuous at a nominal 12.2 V output from a 24V nominal supply. Output voltage is adjustable across 10-15 V and the unit is short circuit proof with a remote on/off terminal. It is a voltage converter, not a battery charger; for charging use an Orion-Tr Smart.

The Victron Orion-Tr 24/12-9 (110W) is an isolated DC-DC converter that steps a 24V nominal input down or up to a regulated 12V output, delivering up to 9A continuous at 12.2 V. It provides 110W of continuous output power and uses galvanic isolation of 200VDC between input, output and case, which separates the two circuits and helps suppress ground loops and electrical noise.

The output voltage is adjustable across 10-15 V, so the unit can be trimmed to suit the connected equipment. It is not intended for battery charging, as it has no charge algorithm. For charging a battery from a second source, Victron recommends an Orion-Tr Smart DC-DC charger instead. The converter is short circuit proof and an unlimited number of units can be connected in parallel to increase available output current.

A remote on/off terminal removes the need for a high current switch in the input wiring and can be driven by a low power switch or an engine run/stop signal. Output current is reduced automatically at high ambient temperature to protect the unit, and all connections are made on screw terminals that need no special tools. With the screw terminals oriented downwards the converter carries an IP43 rating.

Features

Isolated DC-DC converter, 24V nominal input to adjustable 12V output
9A continuous output current and 110W continuous output power
Adjustable output voltage across 10-15 V
Galvanic isolation of 200VDC between input, output and case
Short circuit proof and can be paralleled without limit to increase output current
Remote on/off terminal, driven by a low power switch or engine run/stop signal
Screw terminal connections and IP43 protection with terminals oriented downwards
Voltage converter only, not for battery charging (use Orion-Tr Smart for charging)

##Specifications##

Specifications

Input voltage range	16-35 V
Output voltage (nominal)	12.2 V
Continuous output current	9 A at 12.2 V and 25 °C
Continuous output power	85 W at 40 °C
Galvanic isolation	Isolated
Bluetooth	No
Protection category	IP43

Input

Input voltage range	16-35 V
Under voltage shut down	14 V
Under voltage restart	15 V
No load input current	< 40 mA
Current consumption when disabled	< 200 uA via remote port
Input fuse	Internal, not replaceable

Output

Nominal output voltage	12.2 V
Output voltage adjustment range	10-15 V
Output voltage tolerance	+/- 0.2 V
Output ripple	2 mV rms
Continuous output current	9 A at 12.2 V and 25 °C
Maximum output current (10 s)	12.5 A
Short circuit output current	39 A
Continuous output power at 25 °C	110 W
Continuous output power at 40 °C	85 W
Maximum efficiency	85 %

General

Galvanic isolation	200 VDC between input, output and case
Remote on/off	Yes
Protection	Short circuit, high temperature (output current reduces)

Physical

DC connection	Screw terminals
Maximum cable cross-section	6 mm² (AWG10)
Dimensions (h x w x d)	100 x 113 x 47 mm
Weight	0.42 kg

Environmental

Operating temperature range	-20 to +55 °C (derate 3 % per °C above 40 °C)
Humidity	Max. 95 % non-condensing
Protection category	IP43 (with screw terminals oriented downwards)
